Equilibrium Example Problem – Balance


Consider a string with a weight tied to the end. Gravity pulls the string down while the string pulls the weight. These two forces are equal and opposite to each other. Together, they cancel each other out. The weight is “at rest” with no net forces acting on it. This state is known as mechanical equilibrium.

Mathematically, this is expressed as

ΣF = 0

or the sum of all forces acting on a mass is equal to zero. For the weight on a string, the force up is the tension of the string and the force down is the force of gravity pulling the weight. Together, they add up to zero.

Example Problem

A very large cat sits at the center of a swing. Two scales are attached to the ropes.

Equilibrium Cat 1One scale reads 5 kg.
A. What does the second scale read?
B. What is the combined weight of the cat and swing?

Solution

The cat in this situation is in mechanical equilibrium. The force of gravity pulls down on the cat and swing. The force up to counteract this pull must equal the force down.

Since the cat is sitting in the center of the swing, the force up is equally distributed between both ropes. Since one scale reads 5 kg, the other rope should carry the same amount of weight. The second scale will read 5 kg.

The weight of the cat and swing will be the sum of these two up forces.

5 kg (right scale) + 5 kg (left scale)
10 kg

The cat and swing weighs 10 kg.

Let’s look at what happens if the cat scoots to the left a bit.

Equilibrium Cat 2Now the left hand scale reads 7 kg. What will the right hand scale read?

The cat and swing did not change their weight. The weight was just moved around a bit. The cat and swing still pulls down with a weight of 10 kg. Since they are in equilibrium, the forces up will equal the forces down.

10 kg = 7 kg (left scale) + ? kg (right scale)

10 kg – 7 kg = ? kg (right scale)

3 kg = right scale reading.

It is important to remember when a system in mechanical equilibrium the total forces acting on the system are equal to zero.
